Description

Technical Specifications:
Rated input voltage: Three-phase AC 380V±15% 50/60Hz
Rated input current (A): 13.4A
Rated input power (kw): 9 Rated output capacity (X=60%): 80A/112V
Rated no-load voltage (V): 307±5% Rated no-load current (A): ＜1
Energy efficiency grade: Grade 2
Power factor (COSφ): 0.89
Efficiency (η): 90%
Rated duty cycle(40°C): 60% insulation grade: F
Case Protection Class: IP23S
Output current (A): 25 ～ 80
Arc striking current (A): Non high frequency
Maximum cutting through thickness (mm): 40
Quality cutting (mm) (Carbon steel): 25
Quality cutting (mm) (Stainless steel): 20
Piercing cutting thickness (mm): 12
Dimension (L×W×H) (mm): 592×290×503
Net weight (kg): 33

Included:
• Cutting torch
• Gas hose
• Earth lead package
• With wheels
• Compressore 2 HP
