Description

“Technical book “”Pneumatics in theory and practice””,
EN DS3 Pneumatic workstation, double sided for 4 to 6 trainees – assembled, including packaging Base frame 1 grooved plate
1 storage unit completely assembled
Pneumatic accessories Compressor 230 V/50 Hz Accessory set for compressor Coupling plug with 2/2-way directional control valve T plug connector, 6 mm, packaging unit: 10 Plastic tube 6.0 x 1.05, PU, packaging unit: 8 m
Pneumatics – manual/pneumatic operated valves Exercise books for pneumatics – pneumatic operation Exercises with solutions (trainer’s manual)
“”Pneumatics – manual/pneumatic operation (in accordance with BIBB, exercises 1 to 11)””, EN Exercises (trainee’s manual) “”Pneumatics – manual/pneumatic operation (in accordance with BIBB, exercises 1 to 11)””, EN Device set for workstation WS200/DS3 “”Pneumatics – manual/pneumatic operated valves (BIBB 1-11)””, complete, in L-Box Filter regulator 3/2-way directional control valve, 0.5 to 10 bar Pneumatic distributor, 6x Single action cylinder, d = 25 mm, h = 50 mm Double action cylinder, d = 25 mm, h = 100 mm Manometer 0 to 10 bar
3/2-way directional control valve M5, push button
3/2-way directional control valve G1/8, with push button, open when not operated 5/2-way directional control valve G1/8, with spring return, pneumatically operated 3/2-way directional control valve M5, dancing roller
3/2-way directional control valve G1/8, with spring return
5/3-way directional control valve G1/8, pulse, pneumatically operated
5/3-way directional control valve G1/8, with locked center position, pneumatically operated
3/2-way directional control valve M5, adjustable, 2 to 8 bar
2/2-way directional control valve, time delayed, 2 to 30 s Shuttle valve G1/8, OR Dual pressure valve M5, AND Throttle check valve G1/8 Rapid exhaust valve G1/4 Load simulator d = 25 mm, h = 100 mm, m = 3.4 kg Proximity switch, pneumatic, with holder Vacuum gripper TS-EBS Non-return valve, pilot controlled L-Boxx 136
Pneumatics – electrical operated valves Exercise books for pneumatics – electrical operation Exercises with solutions (trainer’s manual)
“”Pneumatics – electrical operation (in accordance with BIBB, exercises ‘ 1 to 16)”” Exercises (trainee’s manual) “”Pneumatics – electrical operation (in accordance with BIBB, exercises 1 to 16)””, EN Expanded device set for workstation WS200/DS3 from “”Pneumatics – manual/pneumatic operated valves (BIBB 1-11)”” to “”Pneumatics – electrical operated valves (BIBB 1-16)””, in L-Box Double action cylinder, d = 25 mm, h = 100 mm Throttle check valve G1/8 3/2-way solenoid valve M5, spring return
5/2-way solenoid valve, G1/8, with spring return
5/2-way solenoid valve, G1/8, pulse L-Box 136 Electrical device set for workstation WS200/DS3
“”Pneumatics – electrical operated valves (BIBB 1-16)”” Control unit housing version, BIBB module Electric cylinder switch with adapter Electrical position sensor with roller lever Mechanical pressure switch, 1 to 16 bar Sensor, inductive Sensor, capacitive Cable set BIBB electro-pneumatics L-Box 136 Pneumatic accessory set, in L-Box Plastic tube 4 x 0.75, PU, ​​black, packaging unit: 10 m T plug connector, 4 mm, packaging unit: 10 Pipe cutter End plug 4 mm, packaging unit: 20 Loosening tool Silencer G 1/8, packaging unit: 10 Plastic tube 6.0 x 1.05, PU, packaging unit: 2 m L-Box 136
