Description

Technical Data:
MIG-MAG Welding range (in A) :
25-350 Voltage setting :
infinitely variable Duty cycle Duty cycle 100% 40 °C (in Amps) :
260 Duty cycle 60% 40 °C (in Amps) :
300 Duty cycle at max. current 40 °C (in %) :
30% Feeder and wire Wire feed unit :
4 rolls (2 driven) Weldable wires steel (in mm) :
0,6-1,2 Weldable wires alumunium (in mm) :
1,0-1,2 Mains voltage (in V) : 400 Phases (50/60 Hz) :
3~ Positive mains tolerance (in %) :
15% Negative mains tolerance (in %) :
15% Mains fuse (in Amps) :
16 Mains plug :
CEE 16 Dimensions and weights Dimensions (LxWxH) (in mm) :

— Power source dimensions (LxWxH) A version (in mm) : 1116x463x812
Power source dimensions (LxWxH) B version (in mm) : 1116x445x855
Weight (in kg) : — Weight, power source A-version Gas-cooled (in kg) :
92,8 Weight, wire feed case (workshop version) (in kg) :
20,2 Weight, water cooling (filled) (in kg) :
14,7 Standards and approvals standard :
EN 60974-01 protection class (EN 60529) :
IP23 insulation class :
F designation :
CE, S Include Accessories :
▪ MIG Gun ▪ Ground cable ▪ Ground clamp ▪ Gas regulator
